V850
RS850-AFBAG1-US; RS-850-AFBA-G1


Disclaimer: Displayed parts and accessories may not be included in the actual product package.

Description

Developed to be the highest quality, Cooler Master carefully sourced every aspect of the V Series PSU line to produce a high-efficiency and stable power supply. It's highly efficient even at low loads, extremely stable, and works well beyond the parameters of 80PLUS specifications.

  • Fully modular cable design incorporates a single 850W +12V output that delivers up to 70A
  • 80 PLUS Gold certified: up to 93% efficiency @ 50% load
  • Silent 135 mm FDB fan for lower noise and longer lifespan
  • Six PCI-E 6+2 pin connectors to support high-end GPUs
  • 100% high quality Japanese capacitor ensures performance and reliability.
  • Reliable 5 year warranty




Specs

Model RS850-AFBAG1-US; RS-850-AFBA-G1
Type Intel Form Factor ATX 12V V2.31
Dimension 150 x 170 x 86mm / 5.9 x 6.7 x 3.4 inch
Input Voltage 90-264Vac (Auto Range)
Input Current 10 - 5A
Input Frequency Range 60 - 50Hz
PFC Active PFC (>0.9)
Power Good Signal 100-500ms
Hold Up Time >17ms
Efficiency 90% Typical
MTBF >100,000 Hours
Protection OVP/UVP/OPP/OTP/SCP
Output Capacity 850W
Operation Temperature 0-40°C
Certification CE/TUV/TUV-SUDNRTL/FCC/GOST/CCC/BSMI/C-tick/KCC
Fan Silent FDB 135mm
Connector M/B 20+4 Pin x 1
CPU 4+4 Pin x 1
PCI-e 6+2 Pin x 6
SATA x 9
4 Pin Peripheral x 4
4 Pin Floppy x 1
Warranty 5 years
UPC Code 884102020780
  • +
    • Click logo to read full review:
      Hitechlegion.com: Editors Choice
      Hitechlegion.com : September 2013


      "The V-Series gives Cooler Master a PSU line that joins the ranks of the elite and is a perfect complement to the rest of their line-up. Performance and build quality of the V850 are top notch, and definitely among the best we have ever seen. The all black cable system has an excellent look, and the flat modular design makes for easy cable routing, though the layout may cause additional cables to be needed. Frankly, the need for an extra cable is a small price to pay for top notch power delivery and efficiency, and that is exactly what the V850 gives you. The V850 takes home a Hi Tech Legion Editor’s Choice Award and is highly recommended."

      » Details
      Jonnyguru: Recommended
      jonnyguru.com : August 2013


      "Coolermaster has done nearly everything right with the new V series units. They picked a supplier who is obviously on top of the world right now, they've marketed an outstanding platform conservatively when it comes to the efficiency certifications, and they've pretty much tried as hard as they can to toss something my way as close to perfection as possible. And it paid off. Look up there... see how close they came to tens across the board? Only a small handful of units have ever gotten closer than this. Yes sir, this one's an easy recommendation for sure. "

      » Details
      tweaktown.com
      tweaktown.com : August 2013


      "The V850 sports all of the same features and the performance is very close to that of the V1000 in Voltage regulation, DC output quality and efficiency, which is great to see."



      » Details
      Funkykit.com: Recommended
      Funkykit.com : July 2013


      "This is a very good PSU.

      CoolerMaster has said that they were stepping things up in the PSU game, and if this V850 is any indication they are doing exactly that.

      It looks great, I especially like the rounded metal around the modular connectors instead of the standard sharp edges.

      It's quiet up until high heat high load, which is nice. At full tilt the fan isn't the quietest, but it's not the noisiest either. If you can put that much of a load on it you have a few GPUs running full tilt as well, not quiet."



      » Details
      Pureoverclock: Editors Choice
      Pureoverclock.com : July 2013


      "In terms of performance, the V Series units finished spectacularly well, with nominal movement on the rails in our voltage regulation testing, while the ripple results were also excellent. Seasonic is the OEM here, and they typically produce some of the very best power supplies on the market, and it’s no different with the V Series."

      » Details
      Umlan.com: 10/10
      Umlan.com : June 2013


      "Over all performance of V850 is very much solid and very quiet. The Ultra Silent Long Life 135mm fan definitely does its job. We have spent roughly two weeks working with V850 and haven't experienced any problems or glitches in power. Full modular cable design here is great. Use cables you need, none that you don't."

      » Details
  • +
  • +
  • +
